特点 Features
全通径 Full port.1/4"-4"(DN6~DN100)
工作压力W.P.:1000WOG(PN63)
工作温度W.T.:-20℃-180℃
精密铸造 Investment casting
阀杆防爆出装置设计BIoW- out proof stem
双蝶形弹簧动负载设计Live- loading design
防静电装置(可选)Anti- static device(option)
手柄带锁装置(可选) Locking device handle( option)
ISO5211直装高平台设计ISO5211 Direct mounting pad
自动化装置(可选) Automation accessories( option)
螺纹连接标准 Thread type: ASME B1.20.1(NPT)
DIN259/DIN2999,BS21,lSO288-1,lSO7-1
